PIPE BEVELING MACHINE

The ID-Mounted beveling operation use an expandable mandrel which is insert into the open end of the pipe. Tighten

draw nut extend the expanding blocks and against the ID surface for positive mounting, self centered and squared to the bore. As the tool bit is fed into the pipe from the end, a bevel is finished which conforms to the bevel angle required. Bits are available for practically any material or beveling angle required, and bits can be custom made for any form tooling operation.

Features

• In-Situ cold Beveling improves safety
• Easy installation & Operation
• Self-Centering
• Can be placed in any direction
• Feed ratchet spanner makes tool feed or back easily
• Compact design & Light weight
• Electric/ Pneumatic driven for option
• Adjust Speed

Application

• Oil & Gas filed
• Power Plant
• Chemical Plant
• Nuclear Power Plant
• Process Plant & Fabrication
• Ship Building & Repair

Specification

• Drive Options: Pneumatic, Electric
• Air requirement: 900L-1200L/Min@0.6Mpa
• Electric requirement: 220-240V 1PH 50/60HZ
• Feed mode: Feed spanner, manually
• Packaging: Plywood case

Selection Guide

Typical Buttwelding Joint
